| Item Name: | TB6600 Stepper Motor Driver for Nema 17 and Nema 23 Stepper Motor. Ship to Canada, USA. Toronto |
| Specification | DC 9-42V power supply; Subdivision accuracy 1-32 subdivision optional; Output peak current 4.0A; Support Nema17, Nema23 Stepper Motor; |
| PCs in Item: | 1 PC Driver or Drive and Bracket Kit (Driver x 1, 35mm Din Rail Mounting Bracket with screws) |
| Manufacturer: | Multiple, Made in China |
| Notes: | The mounting bracket is for TB6600 and 35mm Din Rail only. Basic Version: Plastic Shell Advanced Version: Metal Shell, Enlarged the heatsink |
| Basic Version | Advanced Version | |
| Design | Plastic Sheel | Metal Sheel |
| Heatsink | Common size Heatsink | Enlarged Size Heatsink |
| Size (L x W x H, mm) | 96 x 27 x 56.5 | 96 x 34.5 x 56.5 |
| Power | DC 9-24V | DC 9-24V |
| Peak Current | 4A | 4A |
| Max Step | 32 | 32 |
| Max Pulse/Res | 3200 | 3200 |
