| Full Mechanical Motion Parts |
C-Beams, Fasteners, Corner Brackets, All Gantry Sets, T8 Screws, T8 Rotating Nuts, Bearing |
Same with Kit A |
Same with Kit A |
Same with Kit A |
Same with Kit A Or Upgraded Ball Screw and Linear Rail Driven) |
| Motors |
N/A |
Three Nema23 Stepper Motors with Driver |
Three Nema23 Stepper Motors with Driver |
Three Nema23 Closed Loop Motors with Driver |
Three Leadshine Nema23 Closed Loop Motors with Driver |
| Motor Mount |
N/A |
Column mounts for each of the motor |
Column mounts for each of the motor |
Nema23 Stepper Motor Mount |
Nema23 Stepper Motor Mount |
| Stepper Motor Coupler set |
N/A |
Plum Coupler |
Plum Coupler |
Single Diaphragm Coupler |
Double Diaphragm Coupler |
| Sensor set |
N/A |
N/A |
6 Sensors |
6 Sensors |
6 Sensors |
| Spindle |
N/A |
N/A |
800 W Water Cooled Spindle Set |
800 W Water Cooled Spindle Set |
800 W Water Cooled Spindle Set with Upgraded Bearings (Or 1.5KW, Air Cooled as options) |
| Controller |
N/A |
N/A |
4 Axis CNC Controller GRBL |
4 Axis CNC Controller FluidNC (Or grblHal) |
4 Axis CNC Controller FluidNC (Or grblHal) |
| Spoil Board/Vise |
N/A |
20cm x 17cm Board with OK Clamp |
20cm x 17cm Board with OK Clamp |
20cm x 17cm Board with OK Clamp |
20cm x 17cm Board with OK Clamp, with mini Visa (Option) |
| Frame Size |
Std |
Std |
Std |
up to 70cm (X Axis) |
up to 100cm (X Axis) |
| Others |
N/A |
N/A |
N/A |
N/A |
Electrical Control Box (More detailed upgrade inside, contact for detail) |
