High Precision 2 Phase NEMA 11 (28 x 28 mm) stepper motor for 3D printer, CNC etc. Multiple length/Torque choices. Ship to Canada, USA.
| Item Name: | NEMA 11 Mini Stepper Motor |
| Specification: | 2 Phase, Step Angle 1.8, NEMA 11 |
| PCs in Item: | 1 PC |
| Manufacturer: | GuangDong, Made in China |
| Model | Step Angle | Holding Torque | Rated Current | Phase Resistance | Phase Inductance | Length | Shaft Length | Shaft Diameter | Weight |
|---|---|---|---|---|---|---|---|---|---|
| 28HS28 | 1.8 | 0.08N.m | 0.8A | 3.2ohm | 1.7mH | 28mm | 15mm | 5mm | 90g |
| 28HS34 | 1.8 | 0.1N.m | 0.8A | 4.3ohm | 3.3mH | 34mm | 15mm | 5mm | 120g |
| 28HS40 | 1.8 | 0.12N.m | 0.8A | 5.1ohm | 3.4mH | 40mm | 15mm | 5mm | 150g |
| 28HS50 | 1.8 | 0.17N.m | 0.8A | 6.5ohm | 6.2mH | 50mm | 15mm | 5mm | 200g |
| Weight | 0.1 kg |
|---|---|
| Dimensions | 8 × 8 × 8 cm |
| Model | NEMA11-28, NEMA11-34, NEMA11-40, NEMA11-50 |
| Brand | HANPOSE |
