Shape K – Synchronous Pulley Wheel for 6mm S3M Belt. Ship to Canada, USA
| Item Name: | Shape K – Synchronous Pulley Wheel for 6mm S3M Belt |
| Material: | Aluminum Alloy |
| Shape Type: | K |
| Timing Belt Fit: | S3M, 6 mm Width |
| Tapping Lock: | Yes |
| PCs in Item: | 1 PC |
| Manufacturer: | N/A, Made in China |
| Model | Shaft (Ø) d (mm) | ØD (mm) | Teeth Width (mm) | H | Overall Width L (mm) |
|---|---|---|---|---|---|
| 20 Teeth-5 | 5 | 22 | 7 | 10 | 18.46 |
| 20 Teeth-6.35 | 6.35 | 22 | 7 | 10 | 18.46 |
| 20 Teeth-8 | 8 | 22 | 7 | 10 | 18.46 |
| 22 Teeth-5 | 5 | 25 | 7 | 10 | 18.6 |
| 22 Teeth-6.35 | 6.35 | 25 | 7 | 10 | 18.6 |
| 22 Teeth-8 | 8 | 25 | 7 | 10 | 18.6 |
| Weight | 0.1 kg |
|---|---|
| Dimensions | 8 × 8 × 6 cm |
| Number of Teeth | 20, 22 |
| Shaft Diameter | 5mm, 6.35mm, 8mm |
| Brand | NOBRAND |
