NEMA 23 Stepper Motor, 8mm Shaft Diameter. Cost-effective Stepper motor for DIY motion control system hobby projects. Ship to Canada, USA.
| Item Name: | PFDE Stepper Motor NEMA 23 |
| Motor Specification: | 2 Phase, Step Angle 1.8, NEMA 23 (57 x 57 mm) |
| PCs in Item: | 1 |
| Manufacturer: | GuangDong, China |
| Model | Step Angle | Holding Torque | Phase current | Length | Shaft Length | Shaft Diameter |
|---|---|---|---|---|---|---|
| 57HS09 | 1.8 | 1.2N.m | 3A | 55mm | 21mm | 8 mm |
| 57HS21 | 1.8 | 1.8N.m | 3A | 76mm | 21mm | 8 mm |
| 57HS22 | 1.8 | 2.3N.m | 3A | 82mm | 21mm | 8 mm |
| 57HS250D | 1.8 | 2.5N.m | 3A | 100mm | 21mm | 8 mm |
| 57HS250H | 1.8 | 2.8N.m | 3A | 112mm | 21mm | 8 mm |
| Weight | 0.5 kg |
|---|---|
| Dimensions | 12 × 8 × 8 cm |
| Torque-Length | 1.2Nm-55, 1.8Nm – 76, 2.3Nm-82, 2.5Nm-100, 2.8Nm-112 |
| Brand | PFDE |
